HEIDENHAIN TNC 320 489
Comparison: Touch probe cycles in the Manual and Electronic Handwheel modes
Cycle TNC 320 TNC 310 iTNC 530
Calibrate the effective length X X X
Calibrate the effective radius X X X
Measure a basic rotation using a line X X X
Set the datum in any axis X X X
Set a corner as datum X X X
Set a center line as datum – – X
Set a circle center as datum X X X
Measure a basic rotation using two holes/cylindrical studs – – X
Set the datum using four holes/cylindrical studs – – X
Set circle center using three holes/cylindrical studs – – X
