456 13 Touch Probe Cycles in the Manual and Electronic Handwheel Modes
13.7 A
u
to
matic W
o
rk
piece Measur
ement
8 Parameter number for result: Enter the number of
the Q parameter to which you want to assign the
coordinate.
8 Probing axis/Probing direction: Enter the probing
axis with the axis selection keys or ASCII keyboard
and the algebraic sign for the probing direction.
Confirm your entry with the ENT key.
8 Position value: Use the axis selection keys or the
ASCII keyboard to enter all coordinates of the nominal
pre-positioning point values for the touch probe.
8 To conclude the input, press the ENT key.
Example: NC blocks
67 TCH PROBE 0.0 REF. PLANE Q5 X-
68 TCH PROBE 0.1 X+5 Y+0 Z-5
