HEIDENHAIN TNC 320
257
8.4 Cy
cles f
o
r Mac
h
ining P
o
int P
a
tt
er
ns
8
Starting point 1st axis
Q225 (absolute value):
Coordinate of the starting point in the reference axis
of the working plane.
8
Starting point 2nd axis
Q226 (absolute value):
Coordinate of the starting point in the minor axis of
the working plane.
8
Spacing in 1st axis
Q237 (incremental value):
Spacing between each point on a line.
8
Spacing in 2nd axis
Q238 (incremental value):
Spacing between each line.
8
Number of columns
Q242: Number of machining
operations on a line.
8
Number of lines
Q243: Number of passes.
8
Angle of rotation
Q224 (absolute value): Angle by
which the entire pattern is rotated. The center of
rotation lies in the starting point.
8
Set-up clearance
Q200 (incremental value): Distance
between tool tip and workpiece surface.
8
Workpiece surface coordinate
Q203 (absolute
value): Coordinate of the workpiece surface.
8
2nd set-up clearance
Q204 (incremental value):
Coordinate in the tool axis at which no collision
between tool and workpiece (clamping devices) can
occur.
8
Moving to clearance height
Q301: Definition of how
the tool is to move between machining processes.
0: Move to the set-up clearance between operations.
1: Move to the 2nd set-up clearance between
machining operations.
Example: NC blocks
54 CYCL DEF 221 CARTESIAN PATTERN
Q225=+15 ;STARTING PNT 1ST AXIS
Q226=+15 ;STARTING PNT 2ND AXIS
Q237=+10 ;SPACING IN 1ST AXIS
Q238=+8
;SPACING IN 2ND AXIS
Q242=6
;NUMBER OF COLUMNS
Q243=4
;NUMBER OF LINES
Q224=+15 ;ROTATIONAL POSITION
Q200=2
;SET-UP CLEARANCE
Q203=+30 ;SURFACE COORDINATE
Q204=50
;2ND SET-UP CLEARANCE
Q301=1
;MOVE TO CLEARANCE
