354 10 Programming: Q Parameters
1
0
.8 A
d
ditional F
u
nctions
11 Tool no. Current tool age CUR. TIME
12 Tool no. PLC status
13 Tool no. Maximum tooth length LCUTS
14 Tool no. Maximum plunge angle ANGLE
15 Tool no. TT: Number of teeth CUT
16 Tool no. TT: Wear tolerance in length LTOL
17 Tool no. TT: Wear tolerance in radius RTOL
18 Tool no. TT: Rotational direction DIRECT (0=positive/-1=negative)
19 Tool no. TT: Offset for radius R-OFFS
20 Tool no. TT: Offset in length L-OFFS
21 Tool no. TT: Break tolerance for length LBREAK
22 Tool no. TT: Break tolerance in radius RBREAK
23 Tool no. PLC value
24 Tool no. Center misalignment in reference axis CAL-OF1
25 Tool no. Probe center offset in minor axis CAL-OF2
26 Tool no. Spindle angle for calibration CAL-ANG
27 Tool no. Tool type for pocket table
28 Tool no. Maximum speed NMAX
Pocket table data, 51 1 Pocket number Tool number
2 Pocket number Special tool: 0=no, 1=yes
3 Pocket number Fixed pocket: 0=no, 1=yes
4 Pocket number Locked pocket: 0=no, 1=yes
5 Pocket number PLC status
Pocket number of a tool in the
tool-pocket table, 52 1 Tool no. Pocket number
2 Tool no. Tool magazine number
Immediately after TOOL CALL
programmed values, 60 1 - Tool number T
2 - Active tool number
0 = X 6 = U
1 = Y 7 = V
2 = Z 8 = W
Group name, ID number Number Index Meaning
