348 10 Programming: Q Parameters
1
0
.8 A
d
ditional F
u
nctions
FN16: F-PRINT: Formatted output of texts or
Q parameter values
The function FN16: F-PRINT transfers Q parameter values and texts in
a selectable format through the data interface, for example to a printer.
If you save the values internally or send them to a computer, the TNC
saves the data in the file that you defined in the FN 16 block.
To output the formatted texts and Q parameter values, create a text
file with the TNC’s text editor. In this file you then define the output
format and Q parameters you want to output.
Example of a text file to define the output format:
“TEST RECORD IMPELLER CENTER OF GRAVITY”;
“DATE: %2d-%2d-%4d”,DAY,MONTH,YEAR4;
“TIME: %2d:%2d:%2d”,HOUR,MIN,SEC;
“————————————————————————“
“NO. OF MEASURED VALUES : = 1”;
“*******************************************“;#
“X1 = %9.3LF”, Q31;
“Y1 = %9.3LF”, Q32;
“Z1 = %9.3LF”, Q33;
“******************************************“;
1080 Calculated values incorrect
1081 Contradictory measuring points
1082 Clearance height entered incorrectly
1083 Contradictory type of plunging
1084 Machining cycle not permitted
1085 Line is write-protected
1086 Oversize greater than depth
1087 No point angle defined
1088 Contradictory data
1089 Slot position 0 not permitted
1090 Enter infeed unequal 0
Error number Text
