356 10 Programming: Q Parameters
1
0
.8 A
d
ditional F
u
nctions
3 - Active mirrored axes
0: mirroring not active
+1: X axis mirrored
+2: Y axis mirrored
+4: Z axis mirrored
+64: U axis mirrored
+128: V axis mirrored
+256: W axis mirrored
Combinations = sum of individual axes
4 1 Active scaling factor axis X
4 2 Active scaling factor axis Y
4 3 Active scaling factor axis Z
4 7 Active scaling factor in U axis
4 8 Active scaling factor in V axis
4 9 Active scaling factor in W axis
5 1 3-D ROT A axis
5 2 3-D ROT B axis
5 3 3-D ROT C axis
6 - Tilted working plane active / inactive (–1/0) in a Program
Run operating mode
7 - Tilted working plane active / inactive (–1/0) in a Manual
operating mode
Active datum shift, 220 2 1 X axis
2 Y axis
3 Z axis
4 A axis
5 B axis
6 C axis
7 U axis
8 5th axis
Group name, ID number Number Index Meaning
