8.3 Cy
cles f
o
r Milling P
o
c
k
ets, St
uds and Slots
7 CYCL DEF 213 STUD FINISHING Define cycle for machining the contour outside
Q200=2 ;SET-UP CLEARANCE
Q201=-30 ;DEPTH
Q206=250 ;FEED RATE FOR PLNGNG
,Q202=5 ;PLUNGING DEPTH
Q207=250 ;FEED RATE FOR MILLING
Q203=+0 ;SURFACE COORDINATE
Q204=20 ;2ND SET-UP CLEARANCE
Q216=+50 ;CENTER 1ST AXIS
Q217=+50 ;CENTER 2ND AXIS
Q218=90 ;FIRST SIDE LENGTH
Q219=80 ;SECOND SIDE LENGTH
Q220=0 ;CORNER RADIUS
Q221=5 ;OVERSIZE
8 CYCL CALL M3 Call cycle for machining the contour outside
9 CYCL DEF 5.0 CIRCULAR POCKET Define CIRCULAR POCKET MILLING cycle
10 CYCL DEF 5.1 SET UP 2
11 CYCL DEF 5.2 DEPTH -30
12 CYCL DEF 5.3 PLNGNG 5 F250
13 CYCL DEF 5.4 RADIUS 25
14 CYCL DEF 5.5 F400 DR+
15 L Z+2 R0 F MAX M99 Call CIRCULAR POCKET MILLING cycle
16 L Z+250 R0 F MAX M6 Tool Change
17 TOOL CALL 2 Z S5000 Call slotting mill
18 CYCL DEF 211 CIRCULAR SLOT Cycle definition for slot 1
Q200=2 ;SET-UP CLEARANCE
Q201=-20 ;DEPTH
Q207=250 ;FEED RATE FOR MILLING
Q202=5 ;PLUNGING DEPTH
Q215=0 ;MACHINING OPERATION
Q203=+0 ;SURFACE COORDINATE
Q204=100 ;2ND SET-UP CLEARANCE
Q216=+50 ;CENTER 1ST AXIS
Q217=+50 ;CENTER 2ND AXIS
Q244=80 ;PITCH CIRCLE DIA.
Q219=12 ;SECOND SIDE LENGTH
Q245=+45 ;STARTING ANGLE
Q248=90 ;ANGULAR LENGTH
