346 10 Programming: Q Parameters
1
0
.8 A
d
ditional F
u
nctions
FN14: ERROR: Displaying error messages
With the function FN14: ERROR you can call messages under
program control. The messages were programmed by the machine
tool builder or by HEIDENHAIN. Whenever the TNC comes to a block
with FN 14 in the Program Run or Test Run mode, it interrupts the
program run and displays a message. The program must then be
restarted. The error numbers are listed in the table below.
Example NC block
The TNC is to display the text stored under error number 254:
Error
number
Text
1000 Spindle must be turning
1001 Tool axis is missing
1002 Tool radius too small
1003 Tool radius too large
1004 Range exceeded
1005 Start position incorrect
1006 ROTATION not permitted
1007 SCALING FACTOR not permitted
1008 MIRROR IMAGE not permitted
1009 Datum shift not permitted
1010 Feed rate is missing
1011 Entry value incorrect
1012 Incorrect sign
1013 Entered angle not permitted
1014 Touch point inaccessible
1015 Too many points
1016 Contradictory entry
1017 CYCL incomplete
1018 Plane wrongly defined
1019 Wrong axis programmed
1020 Wrong RPM
1021 Radius comp. undefined
1022 Rounding-off undefined
1023 Rounding radius too large
1024 Program start undefined
1025 Excessive subprogramming
1026 Angle reference missing
1027 No fixed cycle defined
1028 Slot width too small
1029 Pocket too small
1030 Q202 not defined
1031 Q205 not defined
1032 Enter Q218 greater than Q219
1033 CYCL 210 not permitted
1034 CYCL 211 not permitted
1035 Q220 too large
1036 Enter Q222 greater than Q223
Range of error numbers Standard dialog text
0 ... 299 FN 14: Error code 0 .... 299
300 ... 999 Machine-dependent dialog
1000 ... 1099 Internal error messages (see table
at right)
The machine tool builder can change the FN14:ERROR
function. Refer to your machine manual.
180 FN14: ERROR = 254
