ATA-171/172/171P/171M/171+/172+
User’s Guide
5.11.1 Soft-Key Setting (for Phone)
5.11.1 Function
Soft-Key Setting provides Pick-up key and Voice mail key for the phone.
Phone is required to have those 2 keys. SIP Proxy server is required to have
those function.
5.11.2 Instruction
Figure Soft-Key Setting (VoIP Phone Only)
Pick up Key Input the name of the pick up key, can be numbers or signs.
Maximum length is 15 bytes.
The phone is required to have
related keys.
Voice mail Key Input the name of the voice mail key, can be numbers or signs.
Maximum length is 15 bytes. The phone is required to have
related keys.
Submit [Button] Submit the change.
Reset [Button] Clear the change.
5.11.3 Operate Instruction
Step 1: On the main page, select [Phone Setting Soft-Key Setting], enter [Soft-Key Setting]
page, after revising information (e.g. C Pick up kye: *95, Voice Mail Key: *98) (See Figure 1),
then click [Submit].
(Figure 1)
Step 2: After saving change, enter [Note Information] page, “Note Information” will be seen,
then the changing will come into effect.
Step 3: On the main page, select [Save Change] item, enter [Save Changes] page, and execute
the saving command by press [Save]. [Note Information] page will be seen which means
saving successfully. And the system will be restarted, please wait for a while.
Step 4: When listening the voice mail, please press [Voice Mail]. When pick up the phone, please
press [Pick UP]
