Downloading and Broadcasting Firmware
Verilink SCM 6-15
[1,4] QUAD T1 > y
At the prompt select the partition:
Select image to switch to? 1) A 2) B > 2
NOTE: The firmware is always downloaded to the partition B.
The module reboots from the selected partition.
Download Notes QUAD DATA module: after downloading and switching over, you
must wait at least two minutes before restarting the module.
IMUX: occassionally it happens that after a successful download
and automatic switchover a clear alarm message is missed
resulting in an alarm indication where none exists. Clear the alarm
manually in this case.
Confirming the
Firmware
Upgrade
A way to confirm the success of a firmware download is to use the
Administration Menu option
Q) query firmware .
Type the command:
[0.0.0.0] [1,4] QUAD T1 > q
The Query Firmware Report displays:
Figure 6-12 Administration Menu Query Firmware Report
Executing from partition: B Executing from partition: B Executing from partition: B Executing from partition: B
Partition B ver 2.12 Status: Ok
Partition B ver 2.12 Status: Ok Partition B ver 2.12 Status: Ok Partition B ver 2.12 Status: Ok
Partition A ver 1.94 Status: Ok
Partition A ver 1.94 Status: Ok Partition A ver 1.94 Status: Ok Partition A ver 1.94 Status: Ok
Partition RAM ver 2.12 Status: Ok
Partition RAM ver 2.12 Status: Ok Partition RAM ver 2.12 Status: Ok Partition RAM ver 2.12 Status: Ok
Press enter to continue
Press enter to continue Press enter to continue Press enter to continue
[0.0.0.2] [1,4] QUAD T1 >
[0.0.0.2] [1,4] QUAD T1 > [0.0.0.2] [1,4] QUAD T1 > [0.0.0.2] [1,4] QUAD T1 >
