CFN II Quick Reference
38 C09159 Rev. 2238
plug on one end and a DB-9P connector on the other.
The wires connect the spare RS-422 jack on the
interface box to the DB-9S RS-422 loop at the D-
box.
Modular Plug DB-9P Signal Name
1 2 RX+
2 6 RX-
3 3 TX-
4 7 TX+
The wire colors are not significant.
The modular pins are numbered from right to left
when looking at the modular plug from the retainer-
clip side, with the cable inserted into the plug on the
side closest to you.
SDI/Wayne CAT
The keys of the CAT keypad can be configured for
different functions with the TokheimDPT/Wayne
CAT keyboard layout item on page 4 of the SC II’s
SYS_PAR program.
Keypad
The characters that select different functions are
shown below. Note that these characters are case-
sensitive:
Character Function
0-9 Numeric digits 0-9
. Decimal point
E ENTER
C CLEAR
Y Yes
N No
$ Cash
inside
c Cash outside
D Debit inside
d Debit outside
B Credit (bank card inside)
b Credit outside
X CANCEL
x
CLEAR/CANCEL (CLEAR if data
entry started; else CANCEL)
H Help
h
Help/Decimal (Decimal if data
entry started; else Help)
n No/CANCEL (No if in yes/no
state; else CANCEL)
S Start
u unused
key
The numbers of the keypad keys on the CAT are:
1 2 3 4 5
6 7 8 9 10
11 12 13 14 15
16 17 18 19 20
Note that keys on the left half of the keyboard - that
is: 1, 2, 3, 6, 7, 8, 11, 12, 13, 16, 17, and 18 - cannot
be programmed.
The default function arrangement of the CAT keypad
is:
1 2 3 u b
4 5 6 $ B
7 8 9 N Y
C 0 E H X
The string that would be typed into the Tokheim/
DPT/Wayne CAT keyboard layout item in SYS_PAR
to give the CAT keypad function arrangement shown
above is:
123ub456$B789NYC0EHX
SDI Box Switches
MODA/MODB are on switch 7, RESET on switch 8.
For Wayne CAT, SDI #1, make all switches to OFF
(open).
For Wayne CAT, SDI #2, make position 5 ON
(closed), all others OFF (open).
To clear application memory:
1. Close switch position 6
2. Close switch position 8
3. Open switch position 8
4. Wait a few seconds
5. Open switch position 6
