10. Troubleshooting
User Guide Page 27
• If, after following the installation steps, you are still having
problems, close all applications and restart the video capture
workstation. When the workstation comes back online, open
the Windows Device Manager or Mac OS X System Profiler to
confirm that the Frame Grabber is detected.
VGA2USB, DVI2USB, and KVM2USB LEDs
LED Activity Description
Power
(PWR)
Red Normal operation, the Frame Grabber is
receiving power.
Off Power is disconnected from the Frame
Grabber.
Capture
(CAP)
Flashing
Amber
The video capture application is running
and has found the Frame Grabber. The
Frame Grabber is capturing images.
On The Frame Grabber is not receiving a
VGA/DVI signal, or cannot adjust video
capture parameters.
Status
(STAT)
Off The Frame Grabber is not recognized by
the operating system.
Flashing
Green
Normal operation, the Frame Grabber is
initialized and ready to capture.
