Drag Racing Interface 7-1
Section 7: Drag Racing Interface
Sport Insert 0G-164750
Reference Drawing:
Insert; Drag Race Interface .............................................................Drawing A-164750
The sport insert drawing
is located in
Appendix A.
The Quick Start
Reference is located
in Appendix H.
Refer to the
information in
Sections 1.5 – 1.8 to
start the console and
to use the sport
insert. Read the
material carefully }
to fully understand
the following
operating instructions.
If an insert is lost or damaged, a copy of the insert drawing in Appendix A can be used until
a replacement is ordered.
Use the labels provided in Appendix G to attach the correct code number label at the
appropriate location on the sport insert. Write the code number in the boxes below:
Sport Insert Code
If you do not know the code number for your scoreboard, refer to Appendix I in this manual.
If you do not know the model number of your scoreboard, refer to the installation and
maintenance manual provided with the scoreboard.
Figure 8: 0G-164750
