D-2 All Sport 5000 Racing
RTD Item
(Continued from previous page)
Item No. Laps
Lap Time/
Best Lap Time
Black Flag Time of Day
251 Lap x100 Seconds x0.1 Black Flag x10 Minutes x10
252 Lap x 10 Seconds x0.01 Black Flag x1 Minutes x1
253 Lap x1 Seconds x0.001 BLANK BLANK
All Sport 5100 Racing RTD Item Numbers
Codes: 300 – 303
333 – 433
995
Field # Description Length Justify Item
1 Reserved 39 R 1
2 Time of Day (hh:mm:ss) 8 L 10
3 Reserved 153 R 48
4 Current Driver Name 12 L 201
5 Current Lap # 5 R 213
6 Current Car # 3 R 218
7 Current Position 2 R 221
8 Current Speed xxx.xxx 7 R 223
9 Current Lap Time 12 R 230
10
Current Lap # / Lap Time / Black Flag
(see preceding table)
12 R 242
11 Lap Indicator 1 R 254
12 Time Indicator 1 R 255
13 Black Flag Indicator 1 R 256
14 Black Flag Car # 3 R 257
15 ‘Red’ Status 1 R 260
16 ‘Yellow’ Status 1 R 261
17 ‘Green’ Status 1 R 262
18
Current Running Time (Photocell
Operation)
12 R 263
19 Best Lap Time (Photocell Operation) 12 R 275
20 Pos 1 Car # 3 R 287
21 Pos 2 Car # 3 R 290
22 Pos 3 Car # 3 R 293
23 Pos 4 Car # 3 R 296
24 Pos 5 Car # 3 R 299
25 Pos 6 Car # 3 R 302
26 Pos 7 Car # 3 R 305
27 Pos 8 Car # 3 R 308
28 Pos 9 Car # 3 R 311
(Continued on following page)
