CDM-740 Advanced Satellite Modem Revision 0
Ethernet Management MN-CDM740
6–4
6.5 Web Server (HTTP) Interface
The sections that follow describe the functionality of the CDM-740 Advanced Satellite Modem
Web Server (HTTP) Interface. Please refer to Chapter 5. FRONT PANEL OPERATION,
and the Remote Commands Specifications tables found in Appendix D. REMOTE
CONTROL for detailed descriptions of the configuration parameters featured on the individual
Web pages shown in this chapter.
6.5.1 Web Server Introduction
The embedded Web Server application provides the user with an easy to use interface to
configure and monitor all aspects of the CDM-740. These Web pages have been designed for
optimal performance when using Microsoft’s Internet Explorer Version 5.5 or higher (the
examples shown use Internet Explorer Version 6.0).
The user can fully control and monitor base operations of the
CDM-740 from the Web Server Interface. The user may access an
operations page by selecting any one of the available navigation
tabs – and nested tabs, where applicable – located along the top of
each page (right).
6.5.2 Web Server Menu Tree
The menu tree illustrates the options available through this interface:
Home Management Network Demod Decap MOD Statistics Monitor Utility
Main FE Mgt Tuner-1 Tuner-1 Summary
SNMP GE-1 Config Tuner-1
FAST GE-2 Status GE-1
Firmware Utilities GE-2
Auto Logout Modulator
