CDM-740 Advanced Satellite Modem Revision 0
Front Panel Operation MN-CDM740
5–22
5.6.4 Monitor: IP-Stats
View: Mod/Demod GE1 GE2
Clear: Mod Demod GE1/GE2 All (
◄► )
To view IP operating statistics: From the top line of the Monitor: IP-Stats menu, select
Mod/Demod, GE1, or GE2 using the
◄ ► arrow keys, then press ENTER. Examples of the
Mod/Demod and GE statistics screens (where GE# represents GE1 or GE2) are as follows:
View(
v): Demod: 2300
Pkts Mod: 2400
GE# STATS(
v) IN: 2440
Pkts OUT: 2112
For all menus, use the ▲ ▼ arrow keys to scroll through the available statistics. For a list of the
statistics available on these, refer to the table on the following page. Press ENTER or CLEAR to
exit the screen and return to the previous menu.
To clear IP operating statistics: From the bottom line of the Monitor: IP-Stats menu, select
Mod, Demod, GE1/GE2, or All using the
◄ ► arrow keys, then press ENTER.
For any selection, when prompted select No or Yes using the ◄ ► arrow keys, then press
ENTER, as per the following example:
Clear All Stats: No Yes
(
◄► E)
Monitor: IP Æ Stats Submenus – Available Statistics Summary
Statistic Description
Submenu
Mod/Demod GE1 GE2
Pkts Number of packets. X X X
Max Data Rate Maximum Data Rate. X X X
Data Rate Current Data Rate. X X X
MC Dropped Multicast packets dropped. X N/A N/A
UC Dropped Unitcast packets dropped. X N/A N/A
Dropped Total packets dropped. X N/A N/A
Multicast Multicast packets sent/received X X X
Unicast Unitcast packets sent/received. X X X
