CDM-740 Advanced Satellite Modem Revision 0
Remote Control MN-CDM740
A–14
Parameter
Type
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction
& Qualifier)
Response to Query
GE1 Address IG1= 18 bytes
numerical Command or Query.
Sets the IP Address and network prefix for the 10/100/1000 BaseT GE1
Ethernet port, in the form aaa.bbb.ccc.ddd.yy, where:
(Permitted ranges – cannot all be zero)
aaa = 0-223
bbb = 0-255
ccc = 0-255
ddd = 0-255
yy = network prefix (range: 8 to 31)
Other restrictions:
If aaa>191, prefix may not be less than 24.
If aaa>127, prefix may not be less than 16.
Example: IG1=010.006.030.001.24
IG1=
IG1?
IG1*
IG1# IG1? IG1=xxx.xxx.xxx.xxx.yy
(see Description of
Arguments)
GE2 Address IG2= 18 bytes
numerical Command or Query.
Sets the IP Address and network prefix for the 10/100/1000 BaseT GE2
Ethernet port, in the form aaa.bbb.ccc.ddd.yy, where:
(Permitted ranges – cannot all be zero)
aaa = 0-223
bbb = 0-255
ccc = 0-255
ddd = 0-255
yy = network prefix (range: 8 to 31)
Other restrictions:
If aaa>191, prefix may not be less than 24.
If aaa>127, prefix may not be less than 16.
Example: IG2=010.006.030.001.24
IG1=
IG1?
IG1*
IG1# IG2? IG2=xxx.xxx.xxx.xxx.yy
(see Description of
Arguments)
Current
Software
Image IMG= 1 byte, value of
1 or 2 Query Only.
Active software image, where:
1=Bulk Image #1 currently active
2=Bulk Image #2 currently active
IMG=
IMG?
IMG*
IMG# IMG? IMG=x
(see Description of
Arguments)
Management
IP Address IPA= 18 bytes
numerical
Command or Query.
Sets the IP Address and network prefix for the 10/100 Base T Ethernet
management port, in the form aaa.bbb.ccc.ddd.yy, where:
(Permitted ranges – cannot all be zero)
aaa = 0-223
bbb = 0-255
ccc = 0-255
ddd = 0-255
yy = network prefix (range: 8 to 31)
Example: IPA=010.006.030.001.24
IPA=
IPA?
IPA*
IPA# IPA? IPA=xxx.xxx.xxx.xxx.yy
(see Description of
Arguments)
