CDM-740 Advanced Satellite Modem Revision 0
Ethernet Management MN-CDM740
6–22
BUC Section
BUC LO Freq (MHz)
Enter the BUC’s lockout frequency, in MHz. The valid LO range is 3000 to 65000 MHz.
BUC Power Enable
Use the dropdown menu to select the BUC Power Enable as either Off or On.
BUC Output Power Enable
Use the dropdown menu to select the BUC Output Power Enable as either Off or On.
BUC 10 MHz Reference Enable
Use the dropdown menu to select the BUC 10 MHz Reference Enable as either Off or On.
BUC Low Current Limit (mA)
Enter the BUC’s low current alarm limit in mA. The valid low current limit range is from 0 – 4000
mA, in 100mA increments.
BUC High Current Limit (mA)
Enter the BUC’s low current alarm limit in mA. The valid high current limit range is from 0 – 4000
mA, in 100mA increments.
Once the desired configuration settings have been made in this section, click [Submit] as needed
to save these changes.
Actual BUC Voltage (V) read-only
Actual BUC Current (mA) read-only
BUC power supply voltage and current information is continuously monitored and is provided here
on a read-only basis. Click [Refresh] to update these readings.
