Comtech EF Data CDM-740 - Manual (Page 130)

CDM-740 Advanced Satellite Modem Revision 0
Remote Control MN-CDM740
A–16
Parameter
Type
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction
& Qualifier)
Response to Query
Management
Gateway Port MGP 1 byte, value 0
or 1 Command or Query.
Selects which port management traffic should pass, where:
0 = WAN
1 = LAN
When the WAN port is seleted, all management traffic returns to the
WAN port.
When the LAN port is selected, all management traffic returns via the
LAN port and uses the Management IP Gateway as needed.
Example: MPR=1 (use LAN)
MGP=
MGP?
MGP*
MGP# MGP? MGP=x
(see Description of
Arguments)
Management
Link
Configuration MLC= 1 byte, value 0
thru 5 Command or Query.
Management Interface mode, where:
0=Auto Negoiate
1=1000Mbps -Full Duplex
2=100Mbps – Full Duplex
3=100Mbps – Half Duplex
4=10Mbps – Full Duplex
5=10Mbps – Half Duplex
MLC =
MLC?
MLC *
MLC # MLC ? MLC =x
(see Description of
Arguments)
Actual
Negotiated
Port Speed N/A None Query only.
Returns actual negotiated port speed in the form abcd, where:
a is GE 1 negotiated port speed.
b is GE 2 negotiated port speed.
c is the management port negotiated port speed.
a, b, c, d have the following values:
0 = Link down
1=100 Full
2=100 Half
3=10 Full
4=10 Half
5=1000 Full
N/A NPS? NPS=abc
(see Description of
Arguments)
Number of
Unread
stored
Events N/A 3 bytes Query only.
Returns the Number of stored Events, which remain Unread (over
remote control) in the form xxx (0-255).
Example: NUE=126
N/A NUE? NUE=xxx
(see Description of
Arguments)
Rx 1 Route to
Default
Gateway RD1= 1 byte, value 0
or 1 Command or Query.
When enabled, all incoming Unicast traffic not destined to the CDM-740
local network subnet is directed to the configured default Gateway IP,
where:
0=Off (default)
1=on
Example: RD1=1 (pass traffic to the default gateway IP)
RD1=
RD1?
RD1*
RD1# RD1? RD1=x
(see Description of
Arguments)
