CDM-740 Advanced Satellite Modem Revision 0
Remote Control MN-CDM740
A–13
Parameter
Type
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction
& Qualifier)
Response to Query
External
Frequency
Reference EFR=
1 byte, value of
0 thru 6 Command or Query.
0=Internal 10MHz (default)
1=External 1 MHz
2=External 2 MHz
3=External 5 MHz
4=External 10 MHz
5=Internal 10MHz plus output.
This means that the Reference is available on the “Ext Ref” rear
connector (small rear-panel LED indicates when ON).
EFR=
EFR?
EFR*
EFR#
EFR?
EFR=x
(see Description of
Arguments)
Rx 1 Filter on
Sat MAC FM1= 1 byte, value 0
or 1 Command or Query.
When the Satellite MAC is defined, the CDM-740 only routes Unicast
traffic that is specifically addressed to the Satellite MAC, where:
0=Off, do not filter on the Sat MAC (default)
1=On
This value does not affect the processing of multicast packets.
Example: FM1=1 (filter on the Satellite MAC)
FM1=
FM1?
FM1*
FM1# FM1? FM1=x
(see Description of
Arguments)
GE1 Gateway GG1= 15 bytes
numerical Command or Query.
Sets the IP Gateway Address for the GE1 Ethernet port, with the format
aaa.bbb.ccc.ddd. where:
(Permitted ranges – cannot all be zero)
aaa = 0-223
bbb = 0-255
ccc = 0-255
ddd = 0-255
Example: CG1=010.006.030.001
GG1=
GG1?
GG1*
GG1# GG1? GG1=xxx.xxx.xxx.xxx
(see Description of
Arguments)
GE2 Gateway GG2= 15 bytes
numerical Command or Query.
Sets the IP Gateway Address for the GE2 Ethernet port, with the format
aaa.bbb.ccc.ddd. where:
(Permitted ranges – cannot all be zero)
aaa = 0-223
bbb = 0-255
ccc = 0-255
ddd = 0-255
Example: CG2=010.006.030.001.24
GG2=
GG2?
GG2*
GG2# GG2? GG2=xxx.xxx.xxx.xxx
(see Description of
Arguments)
Initialize the
Stored Events
Pointer IEP= None Command only.
Resets internal pointer to allow RNE? queries to start at the beginning of
the stored events log.
IEP=
IEP# N/A N/A
