CDM-740 Advanced Satellite Modem Revision 0
Front Panel Operation MN-CDM740
5–4
5.2.2 CDM-740 Front Panel Menu Matrix
Sect. Menu / Menu Branch Submenu – Available Selections (See Chapt. Sects for nested info)
5.2.1 Opening Screen N/A
5.3 Select (Main) Menu Configuration Test Monitor Store/Ld Utility ODU FAST
5.4 Configuration Tx Rx Clocks Remote IP Misc
5.4.1 (CONFIG:) Tx Tx-IF Freq Power FEC Mod Data Scrambler*
5.4.2 (CONFIG:) Rx Rx-IF Freq FEC Demod Data Descram* Pilot*
5.4.3 (CONFIG:) Clocks Ext-Ref Int-Ref-Adj
5.4.4 (CONFIG:) Remote Local Serial Ethernet
5.4.5 (CONFIG:) IP
(IP): GE1 GE2 Mgmt
(SNMP): Read-Cmty Write-Cmty Trap
5.4.6 (CONFIG:) Misc High-Stab Reference Warmup Delay: Enable/Disable
5.5 Test Mode BERT-State BERT-Pattern
5.5.1 (Test:) Mode Normal Tx-CW Tx-1/0
5.5.2 (Test:) BERT-State Off On
5.5.3 (Test:) BERT-Pattern 2E23-1 2047
5.6 Monitor Live-Alarms Stored-Events Rx-Params IP-Stats
5.6.1 (Monitor:) Live-Alarms Unit Tx Rx
5.6.2 (Monitor:) Stored-Events Clear-All View
5.6.3 (Monitor:) Rx-Params EsNo BER RxLevel
5.6.4 (Monitor:) IP-Stats
View: Mod/Demod GE1 GE2
Clear: Mod Demod GE1/GE2 All
5.7 Store/Ld (Store/Load Configurations) Configuration #X (0-9): Load Store
5.8 Utility Set-RTC Display-Brightness 1:1 1:N Circuit-ID Firmware
5.8.1 (Utilities:) Set-RTC
(Time): (hh/mm/ss)
(Date): (dd/mm/yy)
5.8.2 (Utilities:) Display-Brightness 1 .75 .50 .25
5.8.3 (Utilities:) 1:1 (Press ENTER to force switchover to standby unit)
5.8.4 (Utilities:) 1:N (UNUSED) (UNUSED)
5.8.5 (Utilities:) Circuit-ID (Circuit ID – max length 32 chars)
5.8.6 (Utilities:) Firmware Info Select
5.9 ODU (Outdoor Unit)
(BUC): BUC_LO Power 10M-Ref Alarm Monitor
(LNB): LNB_LO 22K-Tone Polarity
5.9.1 (BUC) BUC_LO
(BUC Lockout Frequency) (MHz)
(Terminal Mix:) +/- TTF
5.9.2 (BUC) Power
(BUC Power Enable): Off/On
(Output Power Enable): Off/On
5.9.3 (BUC) 10M-Ref (BUC 10MHz Reference): Off/On
5.9.4 (BUC) Alarm
(Alarm Limit Low): (mA)
(Alarm Limit High): (mA)
5.9.5 (BUC) Monitor Read-only (BUC Power Monitor) (mA, V)
5.9.6 (LNB) LNB_LO
(LNB Lockout Frequency) (MHz)
(Terminal Mix) +/- RTF
5.9.7 (LNB) 22K-Tone (Rx LNB 22KHz Tone): Off/On
5.9.8 (LNB) Polarity (Rx Polarity): Off Horizontal Vertical
5.10 FAST Options Configure Demo-Mode
5.10.1 (FAST) Options Read-only
5.10.2 (FAST) Config Word1 Word2 Word3
5.10.3 (FAST) Demo-Mode Off/On
