CDM-740 Advanced Satellite Modem Revision 0
Remote Control MN-CDM740
A–20
Parameter
Type
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response
to
Command
Query
(Instruction &
Qualifier)
Response to Query
Equipment ID N/A 36 bytes Query only.
Returns the equipment ID and installed options, where:
AAAA=0740, the modem model number
Installed hardware:
B=Slot 1: TPC/DVB-S2 Mod card
0 = not present, 1=present
ss=spares (4)
Software FAST options:
C=Tx Frequency option
0=70/140MHz, 1= 70/140MHz & L-band
D=Tx Modulation option
0=Standard: QPSK,.
1=Option 0 plus 8-QAM
2=Option 0 plus 16-QAM
3=Option 0 plus option 1 and 2
E= Tx Data Rate option
0= Standard: 16kbps to 512kbps
1= 16kbps to 2048kbps
2= 16kbps to 5000kbps
3= 16kbps to 9980kbps
4= 16kbps to 2048kbps
F=Tx FEC option
0= Standard: TPC
G=Rx 1 FEC and Symbol Rate option
0= Standard: DVB-S to 45Msps
1= Option 1 plus DVB-S2 to 30Msps
2= Option 1 plus DVB-S2 to 47Msps
3= Option 1 plus DVB-S2 to 62Msps
H=Rx 1 Demodulation option
0= Standard: DVB-S QPSK, DVB-S2 Qpsk, 8psk
1= Option 0 plus DVB-S2 16apsk
2= Option 1 plus DVB-S2 32apsk
I=Demodulation Support option
0= Standard: CCM
1= Option 0 plus VCM
ssssssssssssssssssss = spares (20)
N/A EID? EID=AAAABssssCDEF
GHIsssssssssssssssss
sss
(see Description of
Arguments)
