CDM-740 Advanced Satellite Modem Revision 0
Front Panel Operation MN-CDM740
5–16
5.4.5.1 (CONFIG:) IP Æ (GE1 / GE2 / MGMT)
GE1: Addr/Range MAC Gateway
Link-Config NegoSpeed
( ◄► )
GE2: Addr/Range MAC Gateway
Link-Config NegoSpeed
( ◄► )
MANAGEMENT: Addr/Range MAC Gateway
Link-Config NegoSpeed
( ◄► )
Select Addr/Range, MAC, Gateway, Link-Config, or NegoSpeed using the ◄ ► arrow keys,
then press ENTER.
(CONFIG:) IP Æ (GE1 / GE2 / MGMT) Æ Addr/Range
[HEADER] Ethernet IP Address/Range:
192.168.001.002/24
( ◄► E)
Where [HEADER] is GE1, GE2, or MANAGEMENT: To configure the IP Address for the
Ethernet M&C port for this interface, use the ◄ ► arrow keys to select the character to edit, then
the
▲ ▼ arrow keys to edit the value of that digit. Press ENTER when done.
(CONFIG:) IP Æ (GE1 / GE2 / MGMT) Æ MAC
[HEADER] Ethernet MAC Address (Read-Only)
00-06-B0-00-01-06
( ◄► E)
Where [HEADER] is GE1, GE2, or MANAGEMENT: This is a ‘status only’ display showing the
interface MAC address. Exit this read-only screen by pressing ENTER or CLEAR.
(CONFIG:) IP Æ (GE1 / GE2 / MGMT) Æ Gateway
[HEADER] Ethernet IP Gateway:
192.168.001.002
( ◄► E)
Where [HEADER] is GE1, GE2, or MANAGEMENT: To edit the IP Gateway Address for the
Ethernet M&C port for this interface, use the ◄ ► arrow keys to select the character to edit, then
use the
▲ ▼ arrow keys to edit the value of that digit. Press ENTER when done.
(CONFIG:) IP Æ (GE1 / GE2 / MGMT) Æ Link-Config
[HEADER] Link Configuration:
Auto 1000F 100F 100H 10F 10H
( ◄► E)
Where [HEADER] is GE1, GE2, or MANAGEMENT: To configure the line speed and duplex
setting for this interface, use the ◄ ► arrow keys to select the configuration setting, then press
ENTER.
