CDM-740 Advanced Satellite Modem Revision 0
Remote Control MN-CDM740
A–17
Parameter
Type
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction
& Qualifier)
Response to Query
Retrieve next
5 unread
Stored Events N/A 80 bytes Query only.
Returns the oldest 5 Stored Events that have not yet been read over the
remote control, in the form [CR]sub-body[CR]sub-body[CR]sub-body
[CR]sub-body[CR]sub-body, where sub-body=ABCddmmyyhhmmss:
A is the fault/clear indicator:
F=Fault
C=Clear
I=Info
B is the fault type where:
1=Unit
2=Rx 1 Traffic
3=Rx 2 Traffic
4=Tx Traffic
4=Info (Power on/off, or log cleared)
C is Fault Code number, as in FLT? or Info Code, which may be:
0=Power Off
1=Power On
2=Log Cleared
3=Global Config Change
4=Redundancy Config Change
ddmmyy = date stamp.
hhmmss = time stamp.
If there are less than 5 events to be retrieved, the remaining positions are
padded with zeros. If there are no new events, the response is RNE*.
N/A RNE? RNE=[CR]ABCddmmyyhh
mmss[CR]ABCddmmyyhh
mmss[CR]ABCddmmyyhh
mmss[CR]ABCddmmyyhh
mmss[CR]ABCddmmyyhh
mmss
(see Description of
Arguments)
Software Boot
From Slot SBS= 1 byte, value of
1 to 2 Command or Query.
Selects which bulk firmware slot to boot from, where:
0=Latest Firmware (most recent date)
1=Firmware is Slot #1
2=Firmware is Slot #2
SBS=
SBS?
SBS*
SBS# SBS? SBS=x
(see Description of
Arguments)
Rx 1 Satellite
MAC address SM1 12 bytes, alpha-
numerical Command or Query.
Defines or returns the satellite MAC address. This address should be the
MAC assigned by the route defined in the Encapsulator at the uplink
(headend).
Example: SM1=0006B00001C2
SM1=
SM1?
SM1*
SM1# SM1? SM1=aabbccddeeff
(see Description of
Arguments)
SNMP Read
Community SRC= 16 bytes,
characters, no
spaces
Command or Query.
SNMP read community string. Empty string is not allowed
Example: <1/SRC=public
SRC =
SRC! SRC? SRC =x
(see Description of
Arguments)
SNMP
System
Contact SSC= 254 bytes,
characters,
Command or Query.
SNMP System Contact string
Example:
<1/SSC=Joe Net Admin.
If not configured it returns empty string: <1/SSC=
SSC =
SSC! SSC? STC =x [1..254]
(see Description of
Arguments)
