CDM-740 Advanced Satellite Modem Revision 0
Remote Control MN-CDM740
A–15
Parameter
Type
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction
& Qualifier)
Response to Query
Management
IP Gateway IPG= 15 bytes
numerical
Command or Query.
Sets the IP Gateway Address for the Ethernet management port, in the
form aaa.bbb.ccc.ddd, where:
(Permitted ranges – cannot all be zero)
aaa = 0-223
bbb = 0-255
ccc = 0-255
ddd = 0-255
Example: IPG=010.006.030.001.24
IPG=
IPG?
IPG*
IPG# IPG? IPG=xxx.xxx.xxx.xxx
(see Description of
Arguments)
GE1 Link
Configuration LC1= 1 byte, value 0
thru 5 Command or Query.
GE1 Interface mode, where:
0=Auto Negoiate
1=1000Mbps -Full Duplex
2=100Mbps – Full Duplex
3=100Mbps – Half Duplex
4=10Mbps – Full Duplex
5=10Mbps – Half Duplex
LC1=
LC1?
LC1*
LC1# LC1? LC1=x
(see Description of
Arguments)
GE2 Link
Configuration LC2= 1 byte, value 0
thru 5 Command or Query.
GE2 Interface mode, where:
0=Auto Negoiate
1=1000Mbps -Full Duplex
2=100Mbps – Full Duplex
3=100Mbps – Half Duplex
4=10Mbps – Full Duplex
5=10Mbps – Half Duplex
LC2=
LC2?
LC2*
LC2# LC2? LC2=x
(see Description of
Arguments)
Local/Remote
Status LRS= 1 byte, 0 to 3 Command or Query.
Sets user’s Local/Remote status, where:
0=Local
1=Serial Remote Control
2=Ethernet Remote Control
Example: LRS=1 (which is Serial Remote)
LRS=
LRS?
LRS*
LRS# LRS? LRS=x
(see Description of
Arguments)
Management
MAC Address N/A 12 bytes, alpha-
numerical Query only.
Returns the unique MAC Address for the modem.
Example: MAC=0006B00001C2
N/A MAC? MAC=aabbccddeeff
(see Description of
Arguments)
GE1 MAC
Address N/A 12 bytes, alpha-
numerical Query only.
Returns the unique GE1 MAC Address.
Example: MG1=0006B00001C2
N/A MG1? MG1=aabbccddeeff
(see Description of
Arguments)
GE2 MAC
Address N/A 12 bytes, alpha-
numerical Query only.
Returns the unique GE2 MAC Address.
Example: MG2=0006B00001C2
N/A MG2? MG2=aabbccddeeff
(see Description of
Arguments)
