ATEIS IDA8C - Manual (Page 409)

Components of Audio Processor 409
© 2012 ATEÏS
Name Initial Minimum Maximum Precision Unit
Mute - - - - -
Level -100.0 -100.0 20.0 0.1 dB
Element Description
Mute
Mute the sound coming out from the component.
Level
Level of the pink noise.
6.19 Output
6.19.1 Output
Component Template
Component Appearance
Description
The analogue output modules represent the physical analogue outputs accessible on the rear panel
of the device. There are several separate modules for use with each of the audio board. Analogue
input and output modules are added automatically to the DSP window of the relevant processor by
defining their module configuration at the time you create them and should not be altered.
Control Window
