Type of filtering,
Slope
Slope of attenuation.
Bandwidth
Difference between the upper and lower frequencies in a contiguous set of frequencies.(todo
Kevin)
Mute
Mute the filter's module.
Level
Gain of filter's module.
Frequency
Frequency of cut.
Graphical Control Window
Axis
o X: Frequency of output signal(Hz)
o Y: Level of input signal(dB)
Control Points
o Blue: Adjust element Frequency(Horizontal) and Level(Vertical).
o Yellow: Adjust element Bandwidth
