Page 7
MANUAL:
SECTION 1
P7
LYNX 4S Layout
B. Digital Trim T3
D. Steering Tension
Adjustment
E. Brake Limiter
S. Throttle Tension
Adjustment
R. Throttle Trigger
P. 3-Position Slide Switch
N. Battery Cover
O. LED Lamp
Q. Speaker
Should you change the function set-up for the Digital Button, Digital Trim, or Dial, turn off the power switch ONLY
AFTER waiting several seconds. Powering down too quickly may result in your changes being lost.
Note
Tip
Tip
Tip
