HITEC Lynx 4S - Manual (Page 18)

P18
MANUAL:
SECTION 1
Charging (cont.)
When charging with a charger of your own, set the charging amperage to 1A.
Note
Tip Tip
Tip
Charging with CG-S82 (220V)/ CG-S85 (110V):
1. Connect the plug for the overnight charger to the charging port on your Lynx 4S.
2. A red light will glow to indicate active charging.
3. A green light will glow when the device is fully charged.
Although an overnight charger is preferred, you have other options when charging your batteries. If you do not
currently own an overnight charger, remove the battery from your radio and charge the TX battery with a charger
approved for your battery type.
Note
Tip Tip
Tip
If your Lynx 4S is turned on at the time you connect your overnight charger to the charging port, power to the radio
will cut automatically.
Note
Tip Tip
Tip
