MANUAL:

SECTION 3

P43

Sensor (Telemetry Sensor Setup cont.)

This function is only available when the temperature sensor is connected to your Proton 4 receiver.

Note

Tip

Tip

Tip

To use the ‘SPEAK’ function, a micro SD memory card is required. It is recommended that users save their warning
files to the micro SD memory card provided through the Hitec website. Please visit page XX for more details.

Note

Tip

Tip

Tip

TEMP (Temperature Sensor):
Temperature data gathered by the temperature sensor is displayed on-screen. Users can also set a warning
level and spoken audio warning for this function.

The option to set-up warning sounds is available through each sensor’s function screen.

TMP: Temperature via TEMP sensor.
SPEAK: Activate to issue an audio warning via the Lynx 4S speakers.
USE: Issues a warning message when activated.
WARNING: Set the desired warning level.
UNIT: Set the unit of temperature (F or C).

1. Press the Main Dial to access the function menu.
2. Select ‘SERVO’ under the SYSTEM tab.
3. Select ‘TEMP’ from the menu and adjust the options to your preference.

There will be a time delay between the read-out of the audio data and when the data is displayed on-screen.
