HITEC Lynx 4S - Manual (Page 41)

MANUAL:
SECTION 3
P41
RX-Bind (Receiver Binding cont.)
Lynx 4S Bind Process:
1. Press the Main Dial button to access the function menu.
2. Select ‘RX-BIND’ located under the SYSTEM tab.
3. Select the correct receiver.
4. Click ‘START’ at the bottom of the screen. Note that it will now read “BINDING.”
5. The bind is complete when the LED on the transmitter flashes in color.
Repeat the steps above if binding does not take.
Note
Tip Tip
Tip
RF-Scan (Radio Frequency Scanning)
RF-SCAN clears all bind data. Once the RF-SCAN is complete, you will need to re-process the TX/RX bind.
Note
Tip Tip
Tip
Receiver Bind Process (same as AXION and PROTON):
1. Prepare the Lynx 4S for binding.
2. Press the ‘LINK’ button on the receiver and turn the power ON.
3. Once the power is on, release the ‘LINK’ button.
4. Look for a blinking red and blue LED.
5. Binding is complete when the LED glows solidly blue.
6. Press the ESC button on the transmitter twice to leave bind mode.
7. Power your receiver OFF and then back ON to check for binding.
This function improves the signal connection between your transmitter and receiver.
It is highly recommended that you use the RF-SCAN function when operating your model in a new location.
