HITEC Lynx 4S - Manual (Page 44)

P44
MANUAL:
SECTION 3
Sensor (Telemetry Sensor Setup cont.)
VOLT (Voltage Sensor):
Data from the voltage sensor will be displayed on-screen. In this section, users are shown how to set a VOLT
warning level and voice output.
SPEAK: Activate to issue an audio warning via the Lynx 4S speakers.
USE: Issues a warning message when activated.
WARNING: Set the desired warning level.
1. Press the Main Dial to access the function menu.
2. Select ‘SERVO’ under the SYSTEM tab.
3. Select ‘VOLT’ from the menu and adjust the options to your preference.
In order to check voltage on a battery higher than 8.4V, you will need to connect the battery to the SPC
port of the PROTON 4 receiver. A battery under 8.4V can be checked automatically if it is connected to the
receiver or ESC. For more information, please refer to page ______.
This function is only available when a Proton 4 receiver is used.
Note
Tip Tip
Tip
To use the ‘SPEAK’ function, a micro SD memory card is required. It is recommended that users save their warning
files to the micro SD memory card provided through the Hitec website. Please visit page _____ for more details.
Note
Tip Tip
Tip
There will be a time delay between the read-out of the audio data and when the data is displayed on-screen.
Note
Tip Tip
Tip
