SECTION 2
P23
ABS (Anti-Lock Brake cont.)
ST-EXP may be adjusted with an external switch. Please refer to Page 37 for details.
Note
Tip Tip
Tip
Terms for ABS Setting:
USE: Indicates the status (ON/OFF) of ABS [default: OFF]
ON: The starting point of ABS operation when maneuvering the brake trigger [default: 30%]
POW: The angle of the ABS brake power [default: 50%]
DLY: Delays the time of ABS operation after setting the ABS starting point [default: 0ms]
CYL: The recurring engagement time of the ABS brake [default: 100ms]
STL: Steering mixing [default position: OFF]
You may change the ON/OFF steering setting while brakes are activated.
E50%
Steering operation
N50%
Steering operation
LR N 50% 50%
A.B.S operation range
indicated by “”
A.B.S operation range
indicated by “”
A.B.S operation range
indicated by “”
L R N 50% 50%
See below for the ABS operating range when steering under an N50% and E50% setting:
ST-EXP (Steering Exponential)
Enables the user to set their preferred servo operating conditions for steering, with steering response ranging
from more to less sensitive.
1. Press the Main Dial to enter the function menu.
2. Select ST-EXP from the SET 1/2 tab using your Main Dial button’s scroll and click functions.
3. Press the Main Dial button to select the appropriate option.
