HITEC Lynx 4S - Manual (Page 25)

MANUAL:
SECTION 2
P25
ST-D/R (Steering Dual Rate)
Users have the option of increasing or decreasing the servo operation angle with the dual rate adjusting dial
[Default: 100].
1. ST-D/R function is adjusted by the D1 Dial [under MIX mode 1].
2. Press the Main Dial button from the home screen to access the function menu.
3. Select ST-D/R under the SET 1/2 tab with the scroll/click function of the Main Dial button.
4. When the desired option is highlighted, click the Main Dial button to select.
5. The current value of the ST-D/R function is viewable on the right of the home screen in graph form.
Dual Rate is linked to the EPA function, so check the operating angle of the servo before engaging your vehicle. ST-
D/R may be adjusted by external switch. Please refer to Page 38 for details.
Note
Tip Tip
Tip
S-TRIM (Sub Trim)
If the vehicle drives off-center or when the position of the servo affects proper functioning of the servo horn,
change the position of the servo [Default: 0].
1. MIX function settings may cause changes to the channel names.
2. Press the Main Dial button to access the function menu.
3. Select S-Trim from the SET 1/2 tab by using the Main Dial’s scroll and click functions.
4. Click the Mai Dial button when the desired option is highlighted to select.
5. The current sub-trim value is viewable in graph form on the home screen.
Set the S-Trim to ‘0’ and review the location of the horn for proper alignment before installing the servo(s) in your
vehicle. Use the S-TRIM function to adjust and confirm the appropriate center position. If there is a change to the
S-Trim set position while driving, use the Sub-trim to re-adjust.
Note
Tip Tip
Tip
MIX Mode 1 MIX Mode 10
