MANUAL:
SECTION 1
P13
As the owner of a Lynx 4S, you have the ability to replace the factory grip rubber with one more suitable
to your grip size. You may also choose to install a neck strap holder if you’ve found your R/C experience
necessitates it.
1. Pull down and out on the grip rubber in the direction pictured below.
2. Separate the grip rubber completely.
3. Attach the holder mount with two screws to the underside of the grip rubber as indicated.
4. Push the grip rubber back into place.
5. If you are replacing the grip rubber with a thicker version, simply remove the original as described in steps 1 and 2.
Modifying for Left-Hand Users
Be mindful when handling the sharp ends of the wire.
Note
Tip Tip
Tip
The following procedure requires a Phillips screwdriver.
Note
Tip Tip
Tip
1. Disassemble the steering wheel unit. Refer to Page 11 for a detailed explanation.
2. Lift up on the groove under the steering wheel cover located on the back of the radio to separate. Both
front and back covers should now be removed.
3. Push the wire system exposed in the front of the Lynx 4S back through the rear opening you just uncovered.
4. Put the TX back together in reverse order of disassembly after connecting the wire to the wheel unit.
5. Reattach the battery cover on the opposite side.
Rubber Grip and Neck Strap
