HITEC Lynx 4S - Manual (Page 22)

P22
MANUAL:
SECTION 2
ATL (Brake Rate)
The ATL (Adjustable Travel Limiter) affects the braking response of your vehicle. A higher ATL value
corresponds to a firmer braking response (a 100% value is the equivalent of slamming on your brakes), while a
lower setting results in a more gradual stop.
A.T.L. is a supporting function of the Brake EPA settings.
Note
Tip Tip
Tip
1. The ATL value setting can be adjusted with the D2 Dial [under MIX mode 1] shortcut.
2. Alternatively, you can access the ATL function by pressing the Main Dial from the home screen to view the
function menu.
3. Next, select ATL from the SET 1/2 tab by clicking on the tab and then using the Main Dial button to scroll
and highlight “ATL.”
4. Press the Main Dial button to select. Adjust to the appropriate value.
5. You can check the current ATL value setting on the home screen which is viewable on the right-hand side.
ABS (Anti-Lock Brake)
ABS improves braking sensitivity, cornering, and stability under adverse road conditions.
1. Press the Main Dial to view the function menu.
2. Select “ABS” from the SET 1/2 tab by clicking the Main Dial button when
highlighted.
3. Press the Main Dial button to select the channel.
The user must set a lower CYL value when using low speed servos. Be aware that excessive use of ABS may cause
damage to your servos.
Note
Tip Tip
Tip
