The lower pinch rollers will close after a predefined time (see Load Time feature), and you may
release the paper. The printer will automatically feed the paper up the platen.
The cut sheet may also be loaded into the printer by pressing the Load/Park key. See Load Time in
Chapter 4.
CAUTION
IMPROPER MARGIN SETTINGS CAN DAMAGE PRINTHEAD. SEE PAGE 2-8.
REFER TO FORMS THICKNESS ADJUSTMENT ON PAGE 2-13 PRIOR
TO RUNNING PRINTER. IMPROPER FORM THICKNESS
ADJUSTMENT CAN DAMAGE PRINTHEAD!!
Top Of Form Adjustment
When paper is loaded into the printer, the printer automatically positions the paper to print on the
first line of the form. To change the top-of-form using the Set TOF (Top of Form) key, proceed as
follows:
1. Press the Off Line key.
2. To place the printer in Top- < TOF Adj. Mode >
of-Form Adjust mode, press Use Adjust Keys
the Set TOF key. The form
will advance so the first print
line is positioned at the tear
bar for viewing. The following
message appears in the display:
3. Use the Adjust and
Adjust keys to adjust
the form position. Position
the form so the bottom of
the first print line is directly
in front of the tear bar.
2-10
4. Press the Set TOF key to return the form back to print position.
