9. Press the Enter key to save
the setting in non-volatile memory.
10. Press the On Line key to
place the printer back on
line.
RS-232C Serial Interface
 Data Transfer Rates (Baud Rate):
110 2400
300 4800
600 9600
1200 19200
1800 38400
 Synchronization:
Start-Stop Bits
 Data Format:
Start Bit: 1
Data Bits: 7 or 8
Parity: odd, even or no parity
Stop Bit: 1 or 2 for reception
1 for transmission
If the host serial interface is configured for 7 bit data with no parity, data from host computer must
contain two stop bits.
 Handshaking Protocols:
X-ON/X-OFF: (DCI/DC3) In this protocol, the printer will respond with the DC3
(X-OFF) character when:
Print buffer is nearly full.
The cover is open.
Paper out condition exists.
Carriage jam or paper jam condition detected.
Printer is off line.
B-7
P1 Profile One
Font DP10
P1 Profile One
Font DP10
