Serial Interface Enable/Disable
1.
Set the power switch to ON. P1 Profile One
Font DP10
2. Press the Off Line key. P1 Profile One
Font DP10
3. Press the Setup key. The G1 Forms Control
first group will appear on Form Length 66
the top line of the display,
with the first feature of the
group appearing on the bottom
line.
4. Press the Group key until G4 Serial Ctrl
you have accessed Group Baud Rate 9600
4. The display will appear
as shown.
5. Press the Feature key G4 Serial Ctrl
to select the Serial feature. Serial Enable
6. Press the Value key to G4 Serial Ctrl
select Enable. Press the Serial Disable
.4 key to select Disable.
7. Press the Enter key to G4 Serial Ctrl
accept your selection. Serial Disable
The printer is factory set for RS-232 serial interface. If you are using the RS-232 interface, proceed
to Step 11. If you wish to select the RS-422 serial interface, proceed as follows:
8. Press the Feature key G4 Serial Ctrl
to select the Serial feature. Serial RS-232
9. Press the Value key to G4 Serial Ctrl
select the RS-422. Serial RS-422
B-9
