first group will appear on
Form Length 66
the top line of the display
with the first feature of the
group appearing on the
bottom line.
4.
Press the Group key until
G4 Serial Ctrl
you have accessed Group
Baud Rate 9600
4. The display will appear
as shown.
The printer is factory set for RS-232 serial interface. If you are using the RS-232 interface, proceed
to step 9. If you wish to select the RS-422 serial interface, proceed as follows:
5.
Press the Feature key one time. G4 Serial Ctrl
Serial RS-232
6.
Press the Value key to
G4 Serial Ctrl
select RS-422.
Serial RS-422
7.
Press the Enter key to save
G4 Serial Ctrl
your selection.
Serial RS-422
Next, determine the baud rate of the host computer. The printer is factory set for 9600 baud. If the
baud rate for the printer must be changed, proceed as follows.
8.
Press the Feature key
G4 Serial Ctrl
one time.
Baud Rate 9600
9.
Press the Value key to
G4 Serial Ctrl
select the desired baud
Baud Rate 19.2K rate
(19.2K for this example).
Continue configuration of interface setup until proper host-printer communication is complete.
10. Press the Enter key to save
G4 Serial Ctrl
your selection.
Baud Rate 19.2K
1-16
11. Press the Setup key to
Save Profile?
