151450 7-1
Section 7
System Operation
The operation of the 5600 control panel is similar to a conventional 5 zone Fire Alarm
Control Panel. System status and control is segmented into zones even though the
panel supports addressable SLC devices for input and output functions.
Note: ULC version of the panel (5600C) has a built in Alarm Reset and Alarm Silence inhibit of 30 sec-
onds
7.1 System Reset
To reset the system press the RESET key once. All LEDs will light while the system is
being reset. Alarms and Supervisories that were latched will be reset to their normal
state. Outputs that had been activated by any Alarms and Supervisories will be
deactivated.
7.2 Lamp Test
For Lamp test in accordance with ULC-527-99, see 5600C Basic Operating
Instructions.
7.3 System Silence
To Silence the PZT and all silenceable outputs that are active, press the SILENCE key
once. Any silenceable trouble, supervisory or alarm that is silenced will automatically
unsilence if left silenced for 24 hours or if a new trouble, supervisory or alarm event
occurs.
7.4 Acknowledge
Use the ACK key to acknowledge alarm, supervisory and trouble events
7.5 Viewing Active Alarm Points
When one or more SLC points within a zone are in alarm, the alarm LED for that zone
will blink and outputs will activate that are mapped to alarms within the zone. To display
the SLC address of an input point that is in alarm, press the ALARM ID key once and
use the PREV (previous) or NEXT key to scroll through the alarm points. All points that
are in alarm spanning all zones on the control panel will be displayed when using the
scroll keys.
