151450 1-1
Section 1
Introduction
The 5600 Fire Alarm Control / Communicator is an addressable fire control system
that meets the requirements of UL 864, ULC 527, and ULC 559. Unless otherwise
indicated, all references to 5600 also refer to 5600C and 5600HV.
1.1 Overview of Basic System
1.1.1 Hardware Features
• The 5600 has one signaling line circuit (SLC) that supports 25 Honeywell Fire
Systems (HFS) or SK SLC devices, and one SBUS circuit that supports two
remote annunciators.
• 2.0A of output power is available through 2 sets of terminals for notification
appliance circuits or 1.0A for auxiliary power applications. Each circuit is power
limited per UL 864 and can source up to 2.0A
Note: Total output power for all three circuits must not exceed 2.0A.
• Built-in dual phone line, digital alarm communicator/transmitter (DACT).
• Reports events to central station by zone.
• Two general purpose Form C programmable relays.
• One Form C Trouble Relay.
1.1.2 Software Features
• The 5600 is an addressable panel that operates like a 5 zone conventional panel.
• Advanced addressable smoke detector features:
–Automatic drift compensation
–Maintenance alert region
–Point status meets calibrated smoke test requirements for NFPA 72
• Auto learn “JumpStart” feature for easy programming.
• A choice of output patterns available for notification outputs, including ANSI 3.41
temporal signal.
• Built-in synchronization appliance support for Amseco, Gentex
®
, Wheelock
®
, or
System Sensor
®
.
