3-AXIS SYSTEM COMPONENTS
RED offers the following RED 3-Axis Lens Control System components individually, enabling you to customize
your lens control setup. For more information, visit the
ITEM
PART NUMBER
RED
®
3-Axis Lens Control System
760-0147
RED
®
W.M.D. (Wireless Motor Driver)
790-0414
RED
®
T.H.C. (Tactical Hand Controller)
790-0413
RED
®
Lens Control Motor
760-0146
RED
®
Lens Drive Gear M 0.8
760-0139
RED
®
Lens Drive Gear M 0.6
760-0140
RED
®
Lens Drive Gear M 0.5
760-0141
RED
®
Lens Drive Gear M 0.4
760-0142
19mm-to-15mm Rod Reducer Kit
760-0151
RED
®
Lens Control Motor Mounting Bracket (Standard)
760-0137
RED
®
W.M.D. Motor Cable 7-Pin Straight to 7-Pin Right (12")
790-0434
RED
®
W.M.D. Motor Cable 7-Pin Straight to 7-Pin Right (18")
790-0406
RED
®
W.M.D. Motor Cable 7-Pin Straight to 7-Pin Right (24")
790-0412
RED
®
Lens Motor Cable (3.3KΩ version) 18"
790-0439
RED
®
Lens Motor Cable (3.3KΩ version) 24"
790-0438
RED
®
W.M.D. Power Cable 2-Pin 1B to 2-Pin 0B (18")
790-0410
RED
®
W.M.D. Power Cable 2-Pin 1B to 4-Pin XLR (8')
790-0411
RED
®
CAN Command Cable (5')
790-0407
RED
®
CAN Command Cable (50')
790-0408
RED
®
CAN Command Cable (100')
790-0409
REDLINK™-to-T.H.C. Connector Cable (3')
790-0444
RED
®
Start/Stop Cable (1B to Sync, Ctrl, BNC)
790-0415
RED
®
Start/Stop Cable (1B to BNC)
790-0416
RED
®
Start/Stop Cable (1B to 00B Sync)
790-0428
3BNC-to-00 Lemo Sync Cable
790-0154
Accessory Mount (V-Lock)
790-0370
RED
®
T.H.C./W.M.D. Antenna
790-0420
T.H.C. Focus Marking Ring
790-0430
Lanyard, RED Digital Cinema
010-0119
RED
®
Li Battery 7.2V
740-0032
RED
®
Li Battery Charger 7.2V
740-0033
3-Axis Systems Storage Case
790-0421
BNC-TO-BNC Adaptor
790-0435
