RED 3-AXIS LENS CONTROL SYSTEM - Manual (Page 20)

COPYRIGHT © 2014 RED.COM, INC
RED 3-AXIS SYSTEM OPERATION GUIDE
955-0044, REV-D | 20
# CONNECTOR DESCRIPTION COMPATIBLE PARTS PART NUMBERS
3 Iris connector
(7-pin 1B LEMO)
Connect the W.M.D. to the
Iris Lens Control Motor
RED W.M.D. Motor Cable 7-Pin
Straight to 7-Pin Right (12”)
790-0434
RED W.M.D. Motor Cable 7-Pin
Straight to 7-Pin Right (18”)
790-0406
RED W.M.D. Motor Cable 7-Pin
Straight to 7-Pin Right (24”)
790-0412
4 Zoom connector
(7-pin 1B LEMO)
Connect the W.M.D. to the
Zoom Lens Control Motor
RED W.M.D. Motor Cable 7-Pin
Straight to 7-Pin Right (12”)
790-0434
RED W.M.D. Motor Cable 7-Pin
Straight to 7-Pin Right (18”)
790-0406
RED W.M.D. Motor Cable 7-Pin
Straight to 7-Pin Right (24”)
790-0412
5 CAN connector
(4-pin 0B LEMO)
CAN port for T.H.C. wired
communication
RED CAN Command Cable (5') 790-0407
RED CAN Command Cable (50') 790-0408
RED CAN Command Cable (100') 790-0409
6 Expansion port
(14-pin 1B LEMO)
Expansion port to connect to
DSMC via the SYNC port and
control Start/Stop functions
on the DSMC
RED Start/Stop Cable (1B to Sync,
Ctrl, BNC)
790-0415
RED Start/Stop Cable (1B to BNC) 790-0416
RED Start/Stop Cable (1B to 00B
Sync)
790-0428
3BNC-to-00 LEMO Sync Cable 790-0154
BNC-TO-BNC Adaptor 790-0435
7 232/422 port
(10-pin LEMO)
Serial port to communicate
with third-party devices
N/A N/A
8 PWR connector
(2-pin 1B LEMO)
Power in RED W.M.D. Power Cable 2-Pin 1B
to 2-Pin 0B (18”)
790-0410
RED W.M.D. Power Cable 2-Pin 1B
to 4-Pin XLR (8’)
790-0411
9 MicroSD card slot MicroSD card slot for upgrad-
ing W.M.D. firmware
MicroSD card N/A
10 Guide pin 1/4" guide pin to install the V-
LOCK to a DSMC TACTICAL
RIGHT PLATE
1/4" guide pin N/A
