RED 3-AXIS SYSTEM OPERATION GUIDE

955-0044, REV-D | 28

3. Configure Start/Stop in the W.M.D. main menu.

A. Select Start/Stop.
B. Select a start/stop option based on the intended functionality and cables used.

FUNCTIONS

START/STOP CABLE

PART NUMBER

TYPE

Disable Start/Stop

N/A

Off

Start/Stop, Genlock, Time-

code, and Tally with DSMC

RED Start/Stop Cable (1B to Sync, Ctrl,

BNC)

790-0415

EPIC+Tally

Start/Stop, Genlock, and

Timecode with DSMC

RED Start/Stop Cable (1B to BNC)

790-0416

EPIC

Start/Stop with DSMC

RED Start/Stop Cable (1B to 00B Sync) 790-0428

EPIC

Start/Stop

with RED ONE

RED currently does not provide start/

stop cables to connect the W.M.D. to the

RED ONE

N/A

RED ONE

C. Press Select.

W.M.D. LENS PROFILES

The W.M.D. includes default lens profiles, as well as the capability to modify default profiles for fine tuning. Lens

profiles are separated into three (3) menu categories, Prime (default), Zoom (default), and User (modified). If a

modification is made to a lens profile, the modified version can be saved under the User category.
NOTE: If a particular lens does not have a default profile, the W.M.D. will not support metadata. It may still be

compatible with the system. For more information, go to

“3-Axis System Compatibility” on page 54

The following lenses are supported with default profiles in the W.M.D. firmware:

PRIME LENSES

ARRI Ultra Prime: 14mm, 16mm, 20mm, 24mm, 28mm, 32mm, 50mm, 65mm, 85mm, 100mm, 135mm

ARRI Master Prime: 14mm, 16mm, 18mm, 21mm, 25mm, 27mm, 50mm, 65mm, 75mm, 150mm

Cooke S5: 25mm, 32mm, 50mm, 75mm

Cooke S4: 14mm, 18mm, 21mm, 25mm, 27mm, 32mm, 35mm, 50mm, 65mm, 75mm, 100mm, 300mm

Elite Digital: 18mm, 24mm, 35mm, 50mm, 75mm, 100mm, 135mm

Leica Summilux-C: 21mm, 25mm, 40mm, 50mm, 75mm, 100mm

RED PRO PRIME: 18mm, 25mm, 35mm, 50mm, 85mm, 100mm, 300mm

ZOOM LENSES

Angénieux Optimo: 15-40mm, 17-80mm, 30-80mm

ARRI/Fujinon Alura: 18-80mm T2.6

Fujinon Cine: 14.5-45mm T2, 19-90mm

RED ZOOM: 17-50mm, 18-85mm, 18-50mm T3, 50-150mm T3
