RED 3-AXIS LENS CONTROL SYSTEM - Manual (Page 7)

COPYRIGHT © 2014 RED.COM, INC
RED 3-AXIS SYSTEM OPERATION GUIDE
955-0044, REV-D | 7
01
INTRODUCTION
The RED 3-Axis Lens Control System is a versatile and highly accurate wireless lens control system. Use the
RED ® Lens Control Motor, RED ® Tactical Hand Controller (T.H.C.), RED ® Wireless Motor Driver (W.M.D.), and
related RED accessories to configure a low-profile lens control system for your camera rig. This guide provides
setup and operation instructions for the RED Lens Control Motor, T.H.C., W.M.D., and related accessories.
The Tactical Hand Controller is also compatible with the REDLINK™ Bridge for wireless control of supported
Canon ® and Nikon ® motorized lenses. For more information, see the REDLINK Bridge Operation Guide , available
at www.red.com/downloads .
WARNING: ALWAYS use the RED motor cable with the appropriate internal identification resistor when using
RED LENS CONTROL MOTORs with third-party motor drivers. Any damage caused to motors or motor drivers
resulting from the use of third-party cables will not be covered under warranty.
NOTE: The DSMC does not require a minimum firmware version for operation with the W.M.D., T.H.C.,
Lens Control Motor, and other components of the RED 3-Axis Lens Control System.
01
3-AXIS SYSTEM
OVERVIEW
