RED 3-AXIS SYSTEM OPERATION GUIDE

955-0044, REV-D | 10

This section offers condensed installation and operating instructions to help you get started using the

RED 3-Axis Lens Control System. For more detailed information on specific components, please refer to the

respective chapter in this guide.
WARNING: The DSMC

BRAIN

must be powered off during any installation process.

RECOMMENDED EQUIPMENT

The following RED products are suggestions for use, or are used to depict operations within this section:

12 - 18 V DC power source

‒ AC Power Adaptor (DSMC) with REDVOLT

XL Module

‒ RED Quickplate (Short) Module with attached RED BRICK

‒ Backpack Quickplate (Short) with attached RED BRICK

Mounting platform

‒ DSMC Tactical Cage

‒ DSMC Tactical Right Plate

Mounting system

‒ DSMC Modular Assault Plate Pack

‒ Quick Release Platform or Quick Release Platform (Mini)

15mm or 19mm support rods

‒ RED CARBON-X Rod (Carbon Fiber)

‒ Black Rod (Aluminum)

‒ Steel Rod (Steel)

NOTE: For more information and other compatible products, visit the

3-AXIS SYSTEM

LAUNCH SEQUENCE
