B
COMPATIBLE MOTORS
The following motors are currently supported by the RED ® Wireless Motor Driver (W.M.D.) and RED
Tactical Hand Controller (T.H.C.):
RED Lens Control Motor (DLM1)
Element DLM1 (coming soon)
Heden M21VE
Heden M26VE
Preston DM1
Preston DM1x
Preston DM2
COMPATIBLE MOTOR DRIVERS
RED Lens Control Motors are compatible with the following motor drivers, which require a 3.3KΩ resistance,
using the RED Lens Motor Cable (3.3KΩ version):
Bartech ® Focus Device, single-axis system
Preston ® MDR1
Preston MDR2
Preston MDR3
cmotion ® camin ® motor drivers
WARNING: ALWAYS use the RED motor cable with the appropriate internal identification resistor when using RED
Lens Control Motors with third-party motor drivers. Any damage caused to motors or motor drivers resulting
from the use of third-party cables will not be covered under warranty.
NOTE: RED is in the process of testing and developing additional cables with the appropriate internal identifica-
tion resistor to support seamless communication with other third-party motor systems.
COMPATIBLE LENSES
RED Lens Control Motors can be equipped with accessory drive gears to interface with lenses using any of the
following gear modules:
0.8 M
0.4 M
0.5 M
0.6 M
As with most lens control motors, there will be some lenses that will be too large, too heavy, or too stiff for the
motor. Additionally, cold ambient temperatures may also make it more difficult for the motor to rotate the lens.
NOTE: For information about lenses with default profiles, refer to
“W.M.D. Lens Profiles” on page 28 .
3-AXIS SYSTEM
COMPATIBILITY
