RED 3-AXIS SYSTEM OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC 955-0044, REV-D | 53
lens conTrol MoTor
Maximum Peak Torque 0.85 Nm
Maximum Speed 4.5 rev/second
Dimensions Height: 1.75 in. (44.5 mm)
Width: 1.00 in. (25.4 mm)
Depth: 4.50 in. (11.4 mm)
Weight 5.4 oz (155 g)
Material Aluminum
Construction Machined
Coating Black anodized coating
Operating Temperature 1 0˚C to 40˚C (32˚F to 104˚F)
Storage Temperature -20˚C to 50˚C (-4˚F to 122˚F)
Typical Operating
Power Consumption < 10 W
Peak Operating
Power Consumption 25 W
1. The operating temperature range represents the low and high ambient temperature that the Lens Control Motor operates in without user-
intervention and is consistent with most other professional electronic imaging equipment. Extreme conditions require adequate preparation
and on-set handling. Any damage caused to the Lens Control Motor or your camera system caused by operating outside of the specified
temperature range is not covered under any RED warranty.
red li BaTTerY 7.2v
Dimensions Height: 1.50 in. (38.1 mm)
Width: 0.80 in. (20.3 mm)
Depth: 2.20 in. (55.8 mm)
Weight 2.8 oz (78 g)
Battery Capacity 2200 mAh at 7.2 V
Rechargeable Yes
Operating Temperature Range 0˚C to 40˚C (32˚F to 104˚F)
Storage Temperature Range -20˚C to 50˚C (-4˚F to 122˚F)
