Chapter 9 Maintaining the MultiPASS C3000 9-17
Storing a BJ Cartridge
Whenever you unwrap a BJ cartridge, you must either install it in the
MultiPASS C3000 or store it in the Ink Cartridge Storage Box to prevent
the print head from drying and clogging.
❍ When opening the Ink Cartridge Storage Box, press in on
the release tab that locks the cover in place.
❍ You must insert the cartridge correctly or the storage box
will not close.
❍ The protective cap must be removed from the cartridge
before you set it in the storage box.
Ink Cartridge BCl-21
Color
Made in Japan
Color Slot
Ink Cartridge BCl-21 Black
Made in Japan
Black Slot
Color BJ
Cartridge BC-21 Made in Japan
Carefully set
the cartridge in
the storage box.
2
Open the
Ink Cartridge
Storage Box.
1
